HOWO 8x4 371 Truck Mounted Crane

Name: HOWO 8x4 371 Truck Mounted Crane
SKU: 0

Get a quote

Brand ：SINOTRUK HOWO

Product origin ：Shandong, China

Delivery time ：20-30days

Supply capacity ：100 sets/month

All Categories

Quick Message

HOWO 8x4 371 Truck Mounted Crane

Product Description

The ZW GROUP Sinotruk HOWO 371HP 8×4 truck-mounted crane is a heavy-duty integrated engineering vehicle designed for infrastructure, municipal works, mining, and bulk logistics. Built on a reinforced 8×4 chassis, it combines strong load-bearing capacity with a high-tonnage crane for independent loading and transport without external lifting equipment.

Powered by the 371HP WD615.47 engine with 1,500 Nm torque and a 10-speed transmission, it delivers strong traction for rugged and off-road conditions. It supports 12–20 ton straight-boom or knuckle-boom cranes with 360° rotation, multi-stage telescoping, and hydraulic outriggers with safety protection systems. The reinforced Q235B steel cargo bed ensures durability under heavy loads, making it a cost-efficient solution for reducing rental costs and improving productivity in global engineering operations.

Technical Specifications & Configurations

Category	Specification Item	Technical Details
Chassis Parameters	Brand & Model	Sinotruk HOWO 371HP
	Drive Type	8×4 (Dual front steering axles, dual rear driving axles)
	Engine Model & Power	WD615.47 / 371 HP
	Fuel Type	Diesel
	Emission Standard	Euro II / Euro III
	Transmission	HW19710, 10-speed manual gearbox
	Wheelbase	1800 + 3200 + 1350 mm
	Suspension System	Strengthened leaf spring suspension
	Braking & Steering	Air brake (ABS optional) / Hydraulic power steering
Cargo Body Parameters	Cargo Body Type	Flatbed / Fence / Van (custom options available)
	Length Range	8.0 – 9.5 meters
	Width	2.3 – 2.5 meters
	Height (Side Board)	0.6 – 0.9 meters
	Material & Thickness	High-strength steel / Floor thickness: 4–6 mm (reinforced optional)
	Max Loading Capacity	25 – 40 tons (depending on final configuration)
XCMG Crane Parameters	Crane Brand & Model	XCMG GSQZ330
	Crane Type	Folding boom / Knuckle boom
	Max Lifting Capacity	33,000 kg (33 Tons)
	Max Outreach	18 – 21 meters (depending on arm sections)
	Rotation	360° continuous slewing
	Boom Sections	5 – 7 hydraulic arms (optional)
	Outriggers	Front + rear stabilizers or H-type (optional)
	Hydraulic System	High-efficiency, heavy-load resistant multi-way valve + hydraulic pump
	Operating System	Dual-side manual control (wireless remote control optional)

—— FAQ

Q： Which countries do you export to?

A：

We export our trucks and trailers to Africa, Southeast Asia, the Middle East, South America, and other international markets. Our products are widely used in countries such as Nigeria, Ghana, Tanzania, Zambia, Kenya, Mozambique, and Congo.

Q： Can you customize the truck according to our requirements?

A：

Yes. We support customization services including truck color, logo, tank capacity, left-hand drive or right-hand drive, optional equipment, axle configuration, and other special requirements.

Q： What is the production lead time?

A：

Normally, the production time is around 20 to 35 working days after receiving the deposit. The exact delivery time depends on the truck model and customization requirements.

Q： Can I visit your factory before placing an order?

A：

Of course. Customers are welcome to visit our factory in China. We can also provide factory videos, production photos, and online video inspections.

Q： Can your trucks work in high-temperature environments?

A：

Yes. Our exported trucks are suitable for high-temperature and harsh working environments commonly found in Africa and the Middle East.

Q： Do you provide spare parts?

A：

Yes. We can provide original spare parts and wearing parts for all exported trucks and trailers. Spare parts support is available for long-term cooperation customers.
