DONGFENG 6x4 20CBM Garbage Compactor Truck

Name: DONGFENG 6x4 20CBM Garbage Compactor Truck
SKU: 0

Get a quote

Brand ：DONGFENG

Product origin ：Shandong, China

Delivery time ：20-30days

Supply capacity ：100 sets/month

All Categories

Quick Message

DONGFENG 6x4 20CBM Garbage Compactor Truck

Product Description

The ZW GROUP Dongfeng 6x4 20m³ garbage compactor truck is a heavy-duty sanitation vehicle designed for efficient municipal solid waste collection and transfer in urban and suburban areas. Built on a robust 6x4 chassis, it offers strong traction, stable performance, and reliable operation on both city roads and landfill terrain.

It features a 20m³ high-capacity body with bi-directional hydraulic compaction, significantly increasing waste loading efficiency and reducing transport frequency. With an intelligent control system, leak-proof design, and rear-loading mechanism, it ensures safe, efficient, and cost-effective sanitation operations.

Technical Specifications

To provide a clear understanding of the vehicle's capabilities, below are the standard industry specifications for this model. Please note that as a customizable product from ZW Group, specific parameters can be adjusted to meet your exact project requirements.

Specification Category	Parameter Details
Chassis Brand	Dongfeng
Drive Type	6x4 (Left Hand Drive / Right Hand Drive optional)
Fuel Type	Diesel
Overall Dimensions	9950x2500x3350mm
GVW	25000kg
Body Capacity	20 Cubic Meters (20CBM)
Curb Weight	14200kg
Payload	10670kg
Engine Model	Cummins/Yuchai
Engine Power	Approx. 290HP - 340HP (Depending on emission standards)
Wheelbase	4600+1350mm
Emission Standard	Euro 3 / Euro 4 / Euro 5 / Euro 6 (Customizable)
Compaction Ratio	Up to 0.75 - 0.85 t/m³ (Depending on waste type)
Hydraulic System Cycle Time	≤ 25 Seconds
Material	High-tensile wear-resistant carbon steel
Body Capacity	20 CBM
Hopper Volume	2.0m³-2.5m³
Compaction Ratio	1 : 2.5
Cycle Time	≤25s
Discharging Time	≤40s
Sewage Tank Capacity	≥350L

—— FAQ

Q： Which countries do you export to?

A：

We export our trucks and trailers to Africa, Southeast Asia, the Middle East, South America, and other international markets. Our products are widely used in countries such as Nigeria, Ghana, Tanzania, Zambia, Kenya, Mozambique, and Congo.

Q： Can you customize the truck according to our requirements?

A：

Yes. We support customization services including truck color, logo, tank capacity, left-hand drive or right-hand drive, optional equipment, axle configuration, and other special requirements.

Q： What is the production lead time?

A：

Normally, the production time is around 20 to 35 working days after receiving the deposit. The exact delivery time depends on the truck model and customization requirements.

Q： Can I visit your factory before placing an order?

A：

Of course. Customers are welcome to visit our factory in China. We can also provide factory videos, production photos, and online video inspections.

Q： Can your trucks work in high-temperature environments?

A：

Yes. Our exported trucks are suitable for high-temperature and harsh working environments commonly found in Africa and the Middle East.

Q： Do you provide spare parts?

A：

Yes. We can provide original spare parts and wearing parts for all exported trucks and trailers. Spare parts support is available for long-term cooperation customers.
