ISUZU KV100 4x2 5-Ton Flatbed Tow Truck

Name: ISUZU KV100 4x2 5-Ton Flatbed Tow Truck
SKU: 0

Get a quote

Brand ：ISUZU

Product origin ：Shandong, China

Delivery time ：20-30days

Supply capacity ：100 sets/month

All Categories

Quick Message

ISUZU KV100 4x2 5-Ton Flatbed Tow Truck

Product Description

The ZW GROUP Isuzu KV100 4x2 5-ton flatbed wrecker is an agile recovery vehicle designed for urban streets and highway towing operations. Built on the reliable Isuzu KV100 chassis, it features a fuel-efficient, high-torque diesel engine and a tight turning radius, helping reduce overall operating costs.

Its 5-ton flatbed uses high-strength anti-slip steel with anti-corrosion treatment and a hydraulic sliding-tilt system for safe, damage-free loading of cars, SUVs, and light vans. Equipped with a hydraulic winch and rear wheel-lift system, it can tow two vehicles at once. With dual-side ergonomic controls and strict factory testing, it delivers safe, efficient, and reliable performance for roadside assistance and fleet operations.

Technical Specifications

Category	Parameter Specification	Details & Components
Chassis & Model	Chassis Brand / Drive Type	ISUZU KV100 / 4 x 2 Left Hand Drive (RHD Optional)
	Overall dimensions	850024802730mm
	wheelbase	3360mm or 3800mm
	Fuel type	Diesel
Engine	Engine Type	ISUZU Turbocharged Diesel Engine with Intercooler
	Maximum horse power	130HP
	Emission Standard	Euro 5
Performance	Payload Capacity	5 Tons
Performance	Transmission	Manual 5-speed / 6-speed gearbox
Flatbed Assembly	Deck Dimensions (L x W)	Approx. 5,200 mm x 2,300 mm (Customizable)
	Max lifting capacity	5000kg
	Slide Bed Tilting Angle	8° - 12°ultra-low loading angle
Recovery Gear	Hydraulic Winch Capacity	4,000 kg / 5,000 kg with pneumatic clutch
	Steel Wire Rope Length	21 meters to 25 meters
	Rated traction	40KN
	Max towing capacity	5000kg
Electrical & Safety	Warning Systems	Full-length LED amber lightbar, rear working lights
Electrical & Safety	Standard Accessories	Operational straps, wheel chocks, auxiliary toolboxes

—— FAQ

Q： Which countries do you export to?

A：

We export our trucks and trailers to Africa, Southeast Asia, the Middle East, South America, and other international markets. Our products are widely used in countries such as Nigeria, Ghana, Tanzania, Zambia, Kenya, Mozambique, and Congo.

Q： Can you customize the truck according to our requirements?

A：

Yes. We support customization services including truck color, logo, tank capacity, left-hand drive or right-hand drive, optional equipment, axle configuration, and other special requirements.

Q： What is the production lead time?

A：

Normally, the production time is around 20 to 35 working days after receiving the deposit. The exact delivery time depends on the truck model and customization requirements.

Q： Can I visit your factory before placing an order?

A：

Of course. Customers are welcome to visit our factory in China. We can also provide factory videos, production photos, and online video inspections.

Q： Can your trucks work in high-temperature environments?

A：

Yes. Our exported trucks are suitable for high-temperature and harsh working environments commonly found in Africa and the Middle East.

Q： Do you provide spare parts?

A：

Yes. We can provide original spare parts and wearing parts for all exported trucks and trailers. Spare parts support is available for long-term cooperation customers.
